Tungsten Grinder Neutrix

Tungsten Grinder

This Tungsten Grinder from Neutrix is a portable grinding machine for tungsten electrodes.  The unit is both environmentally friendly and able to grind quality points on Tungsten electrodes for TIG and plasma welding which is critical to ensure great welds

Triple use of the Diamond Super Abrasive grinding disk.

Grinder facts:
Electrode size: Ø0.8 – 4 mm
Min. length: 19 mm standard (15 mm with
special electrode clamps)
Angles: 15° – 180° tip angle
(7.5° – 90° grinding angle)

The Neutrix units is equipped with an integrated dust filter, which protects the operator and the environment from unhealthy dust which is produced during the grinding of the electrode/tungsten. The filter is replaceable.

Due to the use of an electrode holder NEUTRIX is able to grind electrodes as short as 15mm with a standard electrode clamp, with a special electrode clamp as short as 8mm can be ground.

The use of the electrode holder also ensure a precise and centred tip.

NEUTRIX is equipped with an inspection cover enabling the operator to see the grinding operation. NEUTRIX is easy to operate, set the required grinding angle, secure the electrode into the holder using the locking devise. The electrode is now set so as to minimise the amount of grinding
required (0,3mm removal).

As something quite unique NEUTRIX is equipped with an eccentric plate, which makes it possible to adjust the grinding position on the face of the wheel, this triples the life of the diamond wheel.

NEUTRIX is supplied in a case fully equipped for use, electrode clamps for
1,6, 2,4 and 3,2 mm Tungsten’s are included, other dimensions are available.

NEUTRIX is CE marked and is manufactured to meet all EU directives.
Power supply: Available in 110V or 230V ·

Motor: 850W
Rpm: 28000 · Weight: 2,8 kg

We offer other styles of Tungsten Grinders, for more information please call us on 028 9046 0541.
